This is Chen Chen Diesel Parts Plant
We are a professional manufacturer of diesel fuel injection parts,such as the head rotor,element(Plunger&barrel),
nozzle,delivery valve,ve pump parts,Test Bench,Nozzle_Tester Pj-60,etc...
All the products are gone through serious and strict quality control process,and have already exported to
various countries of all over the world.Our excellent quality has been performance in various kind of reputation
brand,for instance BOSCH,ZEXEL,DENSO,DELPHI etc...
We obtained our customers kind comment,and all the items are very popular in homeland & oversea.
We believe that there is also a demand for it at your end.Now we enclose a copy of our catalogue for your
reference.Please study it and let us know your comment,so that we may discuss the business prossibilities.
If you willgive us your specific inquiry,that will be most welcome.
Looking forward to hearing from you soon.
Thank you and kindly regards.
Main Technical Parameter of Fuel Injection Pump Test Bench
CC 7.5KW CC 11KW CC 15KW
Rotation speed range of main haft(rpm) 0-4000 0-3000 0-3000
Motor output power(KW) 7.5 11 15
Pump output power(KW) 0.75 0.75 0.75
Height from center line of main shaft to work table(mm) 125 125 125
Rotation direction of main shaft Positive, negative Positive, negative Positive, negative
Testable cylinders of injection pump 12 12 12
Standard model of fuel injector
oil injection count range 0-1000 0-1000 0-1000
Capacity of oil tank (L) >50 >50 >50
Pressure of fuel system High 0-4 0-4 0-4
Low 0-0.4 0-0.4 0-0.4
Supply oil capacity (L/min) >10 >10 >10
Temperature of fuel (°C) 40±2 40±2 40±2
Precise of fuel filter (μ) 5 5 5
Capacity of measuring cup (ml) 45/150 45/150 45/150
Pressure of air way (Mpa) Positive 0-0.3 0-0.3 0-0.3
Negative -0.05 -0.05 -0.05
DC voltage (V) 12月24日 12月24日 12月24日
Package dimension (m)(L??) 2.2?.15?.8 2.2?.15?.8 2.2?.15?.8
Weight (Kg) 900 900 1050
Main Technical Parameter of Fuel Injection Pump Test Bench
Specification CC 18.5KW CC 22KW CC 30KW
Rotation speed range of main shaft (rpm) 0-3000 1-2000 0-1470
Motor output power(KW) 18.5 22 30
Pump output power(KW) 1.1 1.5 1.5
Height from center line of main shaft to work table(mm) 125 125 125
Rotation direction of main shaft Positive, negative Positive, negative Positive, negative
Testable cylinders of injection pump 12 12 12
Standard model of fuel injector
oil injection count range 0-1000 0-1000 0-1000
Capacity of oil tank (L) >50 >100 >100
Pressure of fuel system High 0-4 0-4 0-4
Low 0-0.4 0-0.4 0-0.4
Supply oil capacity (L/min) >10 >20 >20
Temperature of fuel (°C) 40±2 40±2 40±2
Precise of fuel filter (μ) 5 5 5
Capacity of measuring cup (ml) 45/150 45/260 45/260
Pressure of air way (Mpa) Positive 0-0.3 0-0.3 0-0.3
Negative -0.05 -0.05 -0.05
DC voltage (V) 12月24日 12月24日 12月24日
Package dimension (m)(L??) 2.4?.2?.8 2.4?.2?.8 3.0?.2?.8
Weight (Kg) 1050 1200 1350
|
|
| |
|
|
|
